TL-WR740N v4.23 board back view with serial cable soldered
Size of this preview: 800 × 533 pixels. Other resolutions: 204 × 136 pixels 512 × 341 pixels 1024 × 682 pixels 1536 × 1023 pixels 2048 × 1365 pixels
TL-WR740N v4.23 board back view with serial cable soldered ( 2048 × 1365 pixels )
Information
| Title: | TL-WR740N v4.23 board back view with serial cable soldered |
|---|---|
| Date: | 2012/10/21 16:57 |
| Filename: | tl-wr740n-v423-board-serial-cable-solder.jpg |
| Photographer: | PhobosK |
| Format: | JPEG |
| Size: | 189KB |
| Width: | 2048 |
| Height: | 1365 |
| Keywords: | TL-WR740N, board, serial cable |
